Royal Haven is an 8-bedroom duplex house plan in Nigeria, designed for a 60ft x 100ft plot. It covers 308 m² on a 24m x 14m footprint over three floors: ground, first and second. It has a family lounge, a gallery, a void over the sitting room and an outdoor lounge on the top floor.
Table of Contents
ToggleRoyal Haven at a Glance
Details And Specifications
- Plan name: Royal Haven
- Plan ID: PSN00250BA
- House type: Duplex
- Total area: 308 square meters
- Length x width: 24m x 14m
- Suitable land size; 60ft x 100ft
- Floors: 3 (ground floor, first floor and second floor)
- Bedrooms: 8
- Drawings included: Architectural, Structural, Mechanical and Electrical plans
- Bill of quantity: Free with every plan
Who Is This Duplex Plan For?
Royal Haven suits a large household or an extended family that wants every adult or couple to have a separate bedroom. The ground floor has a master’s bedroom and two en-suite bedrooms, so older relatives and visitors do not need to climb the stairs. The first floor has a master’s bedroom, three en-suite bedrooms and a family lounge. The second floor is a private level with a master’s bedroom, a master’s lounge and an outdoor lounge.
The 24m x 14m footprint is long and narrow, so it fits a 60ft x 100ft plot. Before building, confirm the setback and approval rules of your state or local planning authority.
Room-by-Room Layout
Ground Floor
- Entrance porch: You enter the house through a covered porch.
- Sitting room: The sitting room is the main living space. The first floor has a void over it.
- Dining area: The dining area is set aside for meals.
- Kitchen with pantry and balcony: The kitchen has a pantry for supplies. It also has a balcony.
- Laundry: The laundry is a separate room for washing and drying.
- Master’s bedroom with walk-in closet: The ground floor master’s bedroom has a walk-in closet.
- Two en-suite bedrooms: Both of these bedrooms have their own bathrooms.
- Stairs and stairhall: The stairs and the stairhall lead up to the first floor.
First Floor
- Family lounge: The family lounge is a shared sitting space upstairs, so the household can relax without going downstairs.
- Master’s bedroom with walk-in closet: The first-floor master’s bedroom has a walk-in closet.
- Three en-suite bedrooms: All three of these bedrooms have their own bathrooms, so no one shares.
- Terrace and balcony: The first floor has a terrace and a balcony for open-air space.
- Gallery: The gallery is an open walkway on the first floor.
- Void over the sitting room: The void opens up the space above the sitting room and links the two floors.
- General storage: The first floor has a storage room for household items.
- Stairs and stairhall: The stairs and the stairhall connect the first floor to the other floors.
Second Floor
- Master’s bedroom with walk-in closet: The second-floor master’s bedroom has a walk-in closet.
- Master’s lounge: The master has a private lounge on this floor.
- Outdoor lounge: The outdoor lounge is an open-air sitting space on the top floor.
- Storage room: The second floor has its own storage room.
- Stairhall: The stairhall connects the second floor to the floors below.
What Is Included in the Royal Haven Plan?
Each Royal Haven plan comes with:
- Architectural Plan: Floor plans, elevations and sections showing the building arrangement and dimensions.
- Structural Plan: Structural details for the building.
- Mechanical Plan: Plumbing and water supply layout.
- Electrical Plan: Lighting, socket and wiring layout.
- Free Bill of Quantity (BQ): A breakdown of the materials and labour required for construction, helping you prepare your building budget.
Drawing Type
- Working Drawing: Suitable for approval in some states.
- Detailed Drawing: Can be approved anywhere in Nigeria.
Delivery Method
- You can receive your plan as PDF
- Door-step delivery






How Much Does It Cost to Build an 8 Bedroom Duplex?
The cost of building Royal Haven depends on your location, the quality of finishes, the price of materials at the time you build, and whether you use a contractor or manage the project yourself.
A house with three floors needs more foundation, columns, beams and slabs than a one or two-storey house. Royal Haven also has eight bedrooms with several bathrooms, a void, a gallery, balconies and an outdoor lounge. These are the areas where costs add up.
This is why every Royal Haven plan comes with a free bill of quantity. It lists the quantities of blocks, cement, roofing, finishes and labor, so you can price each item at current market rates in your area instead of guessing. Material prices in Nigeria change often, so check them again before you buy.
Frequently Asked Questions
What Land Size Does Royal Haven Need?
Royal Haven is designed for a 60 ft x 100 ft plot. The building footprint is 24 m x 14 m. Check the setback rules of your state or local planning authority before you build, as they affect how the house sits on the plot.
How Many Bedrooms Does Royal Haven Have?
Royal Haven has eight bedrooms over three floors. The ground floor has a master’s bedroom and two en-suite bedrooms. The first floor has a master’s bedroom and three en-suite bedrooms. The second floor has a master’s bedroom.
Does the Plan Come with a Bill of Quantity?
Yes. A free bill of quantity comes with every Bullionrise Consult building plan. It lists the materials and labor needed to build Royal Haven, so you can budget before you start. Request it on WhatsApp.
Can this Plan be Approved by the Governmemt?
The Working Drawing can be approved in some states, and the Detailed Drawing can be approved anywhere in Nigeria. Tell us your state and we will advise you on the right option for Royal Haven.
Can I Change the Layout?
If you want to adjust Royal Haven or need a custom design, message us and our architects will tell you what is possible for your plot and your needs. Let us know what you would like to change.
How Do I Get The Plan?
Chat with us on WhatsApp, tell us you want Royal Haven (PSN00250BA), and we will give you the price and delivery options for PDF or door-step delivery.
Get The Royal Haven Plan
Ready to build? Chat with us on WhatsApp by clicking the request house plan to get the price for Royal Haven (PSN00250BA), request your free bill of quantity, or ask about a custom design. You can also visit our offices in Lekki, Lagos or in Nsukka, Enugu State.
Looking for something different? Browse more apartment plans or see our duplex plans.
